DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

357

Figure 2-25 Managed AP Statistics – VAP window

Use the drop down menu to select AP’s MAC address and VAP’s ID, and click the radio button to select a radio to

view the information about the client failures and number of packets and bytes transmitted and received on each

VAP on specified radio for a particular access point managed by the Switch.

The fields that can be displayed are described below:

Parameter Description

WLAN Packets Received

Total packets received by the AP on this VAP.

WLAN Bytes Received

Total bytes received by the AP on this VAP.

WLAN Packets Transmitted

Total packets transmitted by the AP on this VAP.

WLAN Bytes Transmitted

Total bytes transmitted by the AP on this VAP.

WLAN Packets Received

Dropped

Number of packets received by the AP on this VAP that were dropped.

WLAN Bytes Received

Dropped

Number of bytes received by the AP on this VAP that were dropped.

WLAN Packets Transmit

Dropped

Number of packets transmitted by the AP on this VAP that were dropped.

WLAN Bytes Transmit

Dropped

Number of bytes transmitted by the AP on this VAP that were dropped.

Client Association Failures

Number of clients that have been denied association to the VAP.

Client Authentication

Failures

Number of clients that have failed authentication to the VAP.

After clicking the Distributed Tunneling tab under the Statistics tab, the following page will appear:
