DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

362

After clicking the WIDS AP Rogue Classification tab, the following page will appear:

Figure 2-32 AP RF Scan Status – WIDS AP Rogue Classification window

The fields that can be displayed are described below:

Parameter Description

MAC Address

The MAC address of the detected AP. This could be a physical radio interface or

VAP MAC. For D-Link APs this is always a VAP MAC address.

Status

Display the managed status of the AP, whether this is a valid AP known to the

Switch or a Rogue on the network. The valid values are:

• Managed - The neighbor AP is managed by the wireless system.

• Standalone - The AP is managed in standalone mode and configured as a valid

AP entry (local or RADIUS).

• Rogue - The AP is classified as a threat by one of the threat detection

algorithms.

• Unknown - The AP is detected in the network but is not classified as a threat by

the threat detection algorithms.

Test Description

Display the tests that were performed, which includes the following:

• Administrator-Configured rogue AP

• Managed SSID received form an unknown AP

• Managed SSID from a fake managed AP

• Fake managed AP on an invalid channel

• AP without an SSID

• Managed SSID detected with incorrect security configuration

• Invalid SSID received from managed AP.

• AP is operating on an illegal channel

• Standalone AP is operating with unexpected configuration.

•

Unmanaged AP detected on wired network.

Condition Detected

Display whether the result of the test was true or false.

Reporting MAC Address

Display the MAC address of the AP that reported the test results.

Radio

Display which physical radio on the reporting AP was responsible for the test

results.
