DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide
371
Figure 2-42 Associated Clients Statistics - Summary window
The fields that can be displayed are described below:
Parameter Description
MAC Address
The Ethernet address of the client station.
Packets Received
Packets received from the client station.
Bytes Received
Bytes received from the client station.
Packets Transmitted
Packets transmitted to the client station.
Bytes Transmitted
Bytes transmitted to the client station.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
After clicking the Session Summary tab under the Statistics tab, the following page will appear:
Figure 2-43 Associated Clients Statistics - Session Summary window
