DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide
389
Figure 2-66 Policy Attribute Summary window
The fields that can be displayed are described below:
Parameter Description
Policy Name
The name of this policy.
Policy Type
The policy type.
Class Name
The name of this class.
Attribute
Display the attributes attached to the policy class instances.
Attribute Details
Display the configured values of the attached attributes.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
