DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

391

Figure 3-2 Basic Setup Discovery window

The fields that can be configured are described below:

Parameter Description

L3/IP Discovery

Tick the check box to enable IP-based discovery of access points and peer

wireless switches. Deselect the check box to disable it.

IP List

Display the list of IP addresses configured for discovery. Select one or more entries

and click the Delete button to remove entries from the list.

IP Address

Enter an IP address to add the IP address to the IP List. The maximum entries to

be entered is 256.

L2/VLAN Discovery

Tick the check box to enable L2/VLAN discovery. Deselect the check box to disable

it. The maximum entries to be entered is 16.

VLAN List

Display the list of VLAN for discovery.

VLAN (1-4094)

Enter the VLAN ID to add the VLAN to the VLAN List.

Enter the information in IP Address or VLAN and click the corresponding Add button to add the entry to the list.

Select one or more entries in the IP List or VLAN List and click the corresponding Delete button to remove entries

from the list.

Click the Apply button to accept the changes made.

After clicking the Profile tab, the following page will appear:
