DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

394

channel assignment process.

Available MSC Indices

Tick the check boxes to add MCS Index when operating in 802.11n mode.

Rate Sets (Mbps)

Display the transmission rate sets.

Basic

Tick the check boxes to indicate the data rates that all stations associating with the

AP must support.

Supported

Tick the check boxes to indicate rates that the access point supports. The AP

automatically chooses the most efficient rate based on factors like error rates and

distance of client stations from the AP.

Click the Apply button to accept the changes made.

Click the Clear button to discard the changes made and return to the default settings.

After clicking the SSID tab, the following page will appear:

Figure 3-5 Basic Setup SSID window

The fields that can be configured are described below:

Parameter Description

Wireless Default VAP

Settings

Click to select the radio to configure the settings for before enabling the VAP.

Network

Tick the check box to enable the corresponding VAP on the selected radio. Use the

drop-down menu to select the network to assign to the VAP.

Click the Apply button to accept the changes made.

Click the Edit button to modify settings for the corresponding network.

After clicking the Edit button, the following page will appear:
