DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

400

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

After clicking the MAC Address hyperlink, the following page will appear:

Figure 3-8 Basic Setup Valid AP – Valid Access Point Configuration window

The fields that can be configured are described below:

Parameter Description

MAC Address

Use the drop-down menu to select the MAC address of the AP.

AP Mode

Use the drop-down menu to select one of the three AP modes.

Managed

Select this to have the AP being part of the D-Link Unified Switch,

and it can be managed by the Unified Switch. When Managed is

selected, the following options appear at the bottom half of the

page:

Authentication Password – Tick the Edit check box and enter

the password for the AP to authenticate itself with the switch

upon discovery.

Profile - Use the drop-down menu to select an AP profile to

assign to the AP.

Channel - Use the drop-down menu to select the portion of the

radio spectrum that the radio uses for transmitting and receiving.

Select Auto to automatically scan for the available RF signal to

use.

Power - Enter a number in percentage to set the power level

which affects how far an AP broadcasts its RF signal.
