DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide
403
The fields that can be configured are described below:
Parameter Description
Channel Plan
The 2.4 GHz (802.11b/g/n) and 5 GHz (802.11 a/n) frequencies use different
channel plans. Click the radio button to select the frequency.
Channel Plan Mode Click to select channel assignment mode. The default is Manual.
Fixed Time – Select this to specify the time for the channel plan and channel
assignment.
Manual – Select this to manually run the channel plan algorithm and apply the
channel plan to the APs.
Interval – Select this to have the switch periodically calculating and applying the
channel plan.
Channel Plan History
Depth (0-10)
Enter the number of channel plan history iterations. The default value is 5. The
channel plan history lists the channels the switch assigns each of the APs it
manages after a channel plan is applied. Entries are added to the history
regardless of interval, time, or channel plan mode. The number you specify in this
field controls the number of iterations of the channel assignment.
NOTE: The APs changed in previous iterations cannot be assigned new channels
in the next iteration. This history prevents the same APs from being
changed time after time. The default value is 5.
Channel Plan Interval
(6-24 Hours)
If Interval is selected in Channel Plan Mode, enter an interval, between 6 and 24
hours, at which the channel plan calculation and assignment occurs. The default
value is 6.
Channel Plan Fixed
Time (hh:mm)
If Fixed Time is selected in Channel Plan Mode, enter a fix time at which the
channel plan calculation and assignment occurs. The channel plan calculation will
occur once every 24 hours at the entered time.
Power Adjustment
Mode
Click Manual or Interval to manually or periodically adjust the power of the AP
radio frequency transmission. The default is Manual.
• Manual - The proposed power adjustments are run manually from the Manual
Power Adjustments page.
• Interval - The switch periodically calculates the power adjustments and applies
the power for all APs. The interval period begins when you click Submit.
Power Adjustment
Interval (15-1440
minutes)
Enter the interval to determine how often the switch runs the power adjustment
algorithm. The value takes effect when Interval is selected in Power Adjustment
Mode. The default value is 15.
Click the Apply button to accept the changes made for each individual section.
After clicking the Channel Plan History tab, the following page will appear:
