DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

406

Click the radio buttons to select the radio frequency in order to see its channel plan.

Click the Apply button to accept the proposed channel change.

Click the Clear button to remove the entries.

Click the Start button to manually run the channel plan adjustment feature.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

After clicking the Manual Power Adjustments tab, the following page will appear:

Figure 3-14 RF Management Manual Power Adjustments window

The fields that can be displayed are described below:

Parameter Description

Current Status

Display the Current Status of the plan.

• None - The power adjustment algorithm has not been manually run since

the last switch reboot.

• Algorithm In Progress - The power adjustment algorithm is running.

• Algorithm Complete - The power adjustment algorithm has finished running.

• Apply In Progress - The switch is adjusting the power levels that the APs

use.

•

Apply Complete - The algorithm and power adjustment are complete.

AP MAC Address

Display the AP MAC address.

Location

Display the location of the AP, which is set in the Valid AP database.

Radio

Display the radio.

Current Power

Display the current power level for the AP.

New Power

Display the proposed power level for the AP.

Click the Apply button to accept the proposed power.

Click the Clear button to remove the entries.

Click the Start button to manually run the power adjustment feature.
