DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide
428
associate with the AP using the SSID in the previous field.
Client QoS Bandwidth
Limit Down
Enter the maximum allowed transmission rate from the AP to the wireless client in
bits per second.
Client QoS Bandwidth
Limit Up
Enter the maximum allowed client transmission rate to the AP in bits per second.
Client QoS Access
Control Down
Use the drop-down menu to select the name of the access list applied to traffic in
the outbound (down) direction.
Client QoS Access
Control Up
Use the drop-down menu to select the name of the access list applied to traffic in
the inbound (up) direction.
Client QoS Diffserv
Policy Down
Use the drop-down menu to select the name of the DiffServ policy applied to traffic
from the AP in the outbound (down) direction.
Client QoS Diffserv
Policy Up
Use the drop-down menu to select the name of the DiffServ policy applied to traffic
from the AP in the inbound (up) direction.
Click the <<Back button to discard the changes made and return to the previous window.
Click the Apply button to accept the changes made.
Click the Clear button to discard the changes made and return to the default settings.
After clicking the QoS tab under the Profile Name tab, the following page will appear:
Figure 3-32 AP Profile Configuration – QoS window
The fields that can be configured are described below:
Parameter Description
Access Point Profile
QoS Configuration
Click the radio button to select the radio between 802.11a/n and 802.11b/g/n.
Template
Use the drop-down menu to select the QoS template. Available options are
Custom, Default and Voice. Select Custom to create your own QoS mechanism.
Queue
Display different types of data transmitted from AP to Station (AP EDCA
Parameters) or from Station to AP (Station EDCA Parameters).
AIFS (msecs)
Enter a wait time for data frames.
cwMin (msecs)
Enter the algorithm that determines the initial random backoff wait time (window)
for retry of a transmission.
