DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

449

Figure 4-16 MAC Access Control Lists – Rename window

The fields that can be configured are described below:

Parameter Description

New MAC ACL Name

Enter a new name of MAC ACL.

Click the Apply button to accept the changes made.

Click the Cancel button to discard the configuration.

After clicking the Add / Delete Rules button or the specific MAC ACL Name hyperlink, the following page will

appear:

Figure 4-17 MAC Access Control Lists – Add / Delete Rules window

Click the Add Rule button to create a new rule.

Click the <<Back button to return to the previous window.

Tick the check box and click the Delete button to remove the specific rule.

Click the Refresh button to update the list.

Click the Rule ID hyperlink or the Edit button to modify the specific rule.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

After clicking the Add Rule button, the following page appears:

Figure 4-18 MAC Access Control Lists – Add Rule window

The fields that can be configured are described below:

Parameter Description

Rule ID

Enter an ID for the rule.

Action

Use the drop-down menu to select the ACL forwarding action when a packet
