Book Mode
1136P219AA
1136P219AA
Book Original 1-Sided Copies
Book 1 <1-Sided Book>
Each of the two pages of an open
book is copied onto one side of a
separate sheet of paper.
▼
1136P220AA
1136P220AA
Book
Original
2-Sided
Copy
Book 2 <2-Sided Book>
Each of the two pages of an open
book is copied onto each side of a
sheet of paper.
▼
1136P330CA
Input
Job
Memory
Zoom
Memory
Auto Size
Meter
Count
Toner
Book 1
OHP
Inter-
leaving
Page
Insertion
Cover
(Front)
Book 2
Margin 1
Margin 2
Erase 1
Erase 2
Erase 3
Erase 4
Display
OK
Drum
Dehumidify
Cover
(Front
&
Back)
1136P330CA
You may want to fit each page of an open
book onto a separate sheet.
The copier provides two different Book
functions to choose from. Select one that
best suits yours need.
6. Supplementary Function Setting
Book 2 cannot be combined with the Sort-and-Staple, Cover, Page Insertion,
OHP Interleaving, or Multi Bypass.
NOTE
▼
Chapter 3
Making Copies
106
