Konica Minolta EP2050 [171/225] When a warning message appears

1136O173CA

Check that no portion of the

staple sheet hangs out of the

Cartridge. Break off any

portion of the sheet that hangs

out of the Cartridge.

NOTE

1136O013AA

Insert the new Staple Cartridge

until a click is heard.

1136O167AA

Close the Staple Cover and slide

the Staple Sorter back against the

copier.

2. Detailed Instructions for Messages/Indicator Lights

1136O015AA

Non-Sort Bin

Place a sheet of paper into the 1st

Bin of the Staple Sorter.

1136O016AA

Non-Sort Bin

1st Bin

Sorter

Chapter 5

When a Warning Message Appears

159
