1136P351CA
Job
Memory
Zoom
Memory
1136P351CA
Press the Job Memory Select
Key.
•
The Job Memory LED lights up
steadily and the Zoom Memory
LED goes out.
•
A screen appears on the
Message Display to allow you
to select a memory number.
3
Job Input :
1 2 3 4 5
6 7 8 9 10
1136P389CA
Press the Select Key as necessary
to select the memory number in
which you want to store the
program.
•
Each time the Key is pressed,
the cursor moves to a new
number.
4
If you have set up the job inappropriately or if you want to change it to a new
one, repeat steps 1 through 4.
1136P430AA
OK
OK
1136P430AA
Press the Enter Key.
This stores the job program in
the specified memory number.
5
Input
1136P290CA
1136P290CA
Make the necessary control panel
settings for the job to be stored
in memory.
Press the Memory Input Key.
•
The Job Memory LED and
Zoom Memory LED on the
Supplementary Panel start
blinking.
1
2
Storing a Job Program in Memory
Chapter 3
Making Copies
125
6. Supplementary Function Setting
