2. Paper Feed Cabinet
Name Paper Feed Cabinet PF-102
Type Tandem-paper-loading, 2,500-sheet Cassette
Installation Desk type
Kinds of Paper Plain paper, Recycled paper:
Weighing 60 g/m
2
to 90 g/m
2
Copy Paper Size A4L, Letter C
Registration Front edge
Paper Feeding System Automatic feeding from drawer
Capacity 2,500 sheets (1,250 sheets ×2)
Power Source DC24V supply from copier
Power Consumption Included in 1.5 kW consumed by the copier.
Dimensions Width
Depth
Height
:
:
:
620 mm
695 mm
390 mm
Weight 36.5 kg
Name Paper Feed Cabinet PF-202
Type Paper feeding unit with two drawers
Installation Desk type
Kinds of Paper Plain paper, Recycled paper:
Weighing 60 g/m
2
to 90 g/m
2
Copy Paper Size 3rd drawer: A3L to A5L
4th drawer: A3L to 210 × 280 L
Registration Front edge
Paper Feeding System Automatic feeding from drawer
Capacity 500 sheets/drawer Total: 1,000 sheets
Power Source DC24V supply from copier
Power Consumption Included in 1.5 kW consumed by the copier.
Dimensions Width
Depth
Height
:
:
:
620 mm
695 mm
390 mm
Weight 35.0 kg
Chapter 7
Specifications
194
