Action
Using the Corona Unit Cleaning Levers, clean the Corona Units.
➭
p. 210
Wipe the Original Glass clean with a soft dry cloth.
➭
p. 208
Wipe the Original Pad or Document Feed Belt clean with a soft cloth dampened with
neutral detergent.
➭
pp. 208, 211
Place a blank sheet of paper over the original.
➭
p. 40
The information on the back side of a two-sided, thin original may be slightly reproduced
on the copy. Set the copier into the Manual Exposure Mode and, using the Exposure
Control Key (Lighter), make the exposure level lighter.
➭
p. 49
Wipe the Original Pad or Document Feed Belt clean with a soft cloth dampened with
neutral detergent.
➭
pp. 208, 211
Select the same copy paper size as the original.
➭
p. 60
Or, use the Auto Size Mode to enlarge the copy to the appropriate size.
➭
p. 56
Select the paper drawer that is loaded in the same direction as the original.
➭
p. 60
Or, reload the paper in the same direction as the original.
➭
p. 60
Select the zoom ratio according to the copy paper size.
➭
pp. 58, 217
Or, use the Auto Size Mode to reduce the copy to the appropriate size.
➭
p. 52
Place the original correctly on the Original Glass against the Original Width Scale.
➭
p. 40
Or, load it onto the AF-3/AFR-7 correctly along the Document Guide Plates.
➭
p. 43
Raise the AF-3/AFR-7 and place the originals on the Original Glass one at a time, instead
of using the AF-3/AFR-7.
➭
p. 46
Wipe the Original Glass clean with a soft dry cloth.
➭
p. 208
1. When this Type of Copy is Produced
Chapter 6
Troubleshooting
187
