Konica Minolta EP2050 [201/225] Automatic document feeder
![Konica Minolta EP2050 [201/225] Automatic document feeder](/views2/1122110/page201/bgc9.png)
Name Automatic Document Feeder AF-3
Type Take-up from bottom of stack and U-turn feeding to Glass, U-turn
ejection
Installation On top of copier, with two Hinges at the back
Document Feeding
System
Single Belt transport
Document Stop Reference Left side
Document Feeding
Registration
Rear edge
Document Feeding Standard Mode: 1-sided original
Mixed Original Detection Mode:
1-sided mixed original detection
Lightweight Original Mode
Kinds of Original Plain paper
Original Weight 1-sided Original Mode: 50 to 110 g/m
2
1-sided Mixed Original Detection Mode: 60 to 90 g/m
2
Lightweight Original Mode: 40 to 110 g/m
2
Original Size 1-sided Original Mode
1-sided Mixed Original Detection Mode:
A3L, B4L, A4L, A4C, FLSL
Capacity of Document
Feed Tray
A4L, A4C: 30 sheets (80 g/m
2
)
A3L, B4L: 15 sheets (80 g/m
2
)
Document Loading Face up
Copy Productivity 100%
First copy in automatic
document feeding
10.3 sec. or less
Power Source DC24V supplied from copier
Power Consumption 48W or less
Dimensions Width
Depth
Height
: 590 mm
: 515 mm
: 95 mm (Excluding Document Exit Tray)
Weight 10.0 kg
4. Automatic Document Feeder
Chapter 7
Specifications
197
