4. User’s Choice
Paper Priority
Specifies the paper port selected automatically when the copier is set into either
the Auto Size Mode or Manual Mode.
The initial setting is "1" (1st Drawer).
Exposure Priority
Determines the priority exposure mode, either Auto or Manual, selected when
the control panel settings are reset.
If Auto is selected, this function also allows you to specify the priority
exposure level (EXP) in the Manual Exposure Mode, as it is selected when the
Auto Exposure Mode is canceled.
Exposure Mode (At Reset) Setting
Auto The exposure level can be set ranging between
EXP1 to 9 (level set after Auto is canceled).
Manual The exposure level can be set ranging between
EXP1 to 9.
Use the Exposure Control Keys (Lighter, Darker) to set the exposure level in
the Manual Exposure Mode.
The initial setting is "Auto Exposure" and EXP5 for the priority exposure level
in the Manual Exposure Mode as it is selected when the Auto Exposure Mode
is canceled.
Paper Pr.
2 A4
1 A4
3 A3
4 A4
5
1
1st Drawer
4
4th Drawer
2
2nd Drawer
5
Blank
3
3rd Drawer
1136P544CA
1136P361CA
DarkerLighter
1234 56789
*
With EXP5 at the central level, the
exposure level will be lower as the
number becomes smaller and higher
as the number becomes greater.
1136P361CA
1136P408CA
Expo. Priority :
Auto Exposure
Manual Exposure
1136P408CA
Chapter 4
Special Functions
134
