Indicator/Message Copier State Action
The paper has run out. Add paper by following the
steps given in the "Add Paper
Indicator" section.
➭
p. 148
A copier door is open or an
option is not attached properly.
Check the Monitor Display for
the location of the closure
failure and correct the failure as
instructed.
➭
p. 162
There is a misfed sheet of paper
inside the copier or an option
(including the AF-3/AFR-7).
Check the Monitor Display for
the location of the misfeed and
clear the misfed sheet of paper
as instructed.
➭
p. 166
There is a copy or copies left in
the Sorter Bin(s).
Remove a copy or copies from
the Sorter Bin(s).
The Staple Sorter will soon run
out of staples.
Replace the Staple Cartridge
with a new one by following the
steps given in the "Add Staple
Indicator" section.
➭
pp. 154, 158
A regularly scheduled
preventive maintenance call
becomes necessary.
(Note: A copy cycle can still be
initiated.)
Call your Tech. Rep.
immediately.
The copier has developed a
technical malfunction.
If the Call-Tech.-Rep. Indicator
remains lit even after you have
reset it, call your Technical
Representative.
➭
p. 182
The Plug-In Counter is
unplugged.
Plug in the Plug-In Counter.
1. Quick Reference for Warning Messages and Indicator Lights
Load paper :
x1.000 A4
1136P432CA
1136O432CA
Close section
properly :
1136P375CA
1136O375CA
Remove the paper
at :
1136P376CA
1136O376CA
Remove all the
copies from the
Sorter bins :
1136P378CA
1136O378CA
Replace the
Staple Cartridge
1136P379CA
1136O379CA
Maintenance *
1136P380CA
1136O380CA
Call your
Technical Rep. :
Code : C0610
1136P381CA
1136O381CA
Insert the
Plug-in Counter :
1136P382CA
1136O382CA
Chapter 5
When a Warning Message Appears
145
