Konica Minolta EP2050 [63/225] Making copies

2. Basic Copying Procedure

1136P283CA

Select Zoom#:

>1:<X1.000>

2:<X0.930>

Input

Job

Memory

Zoom

Memory

Meter

Count

1136P283CA

You may want to store frequently

used zoom ratios in memory and call

one up from memory as necessary for

use in your copying job.

Up to two different zoom ratios can

be stored in memory.

The following two zoom ratios have

been factory-set:

Memory 1: ×1.000 (full size)

Memory 2: ×0.930

Zoom Memory

1136P284CA

Auto Size

AUTO

1136P284CA

When in this mode, the copier

automatically selects the zoom ratio

based on the original size and copy

paper size currently selected for use.

Auto Size Mode

Chapter 3

Making Copies
