10. Data Controller
Name Data Controller D-102
Type Magnetically encoded card accessed Copy Counter
Types of Cards Departmental, Register, Administration, Erasing, Time/Date, and
Cleaning Card
Departmental Cards
Accommodated
Up to 999 groups
Display 7-segment, 16-digit liquid-crystal display
Copy Count to be Stored
in Memory
•
Max. no. of copies made, total: 9,999,999
•
Max. no. of copies made, by paper size: 9,999,999
•
Max. no. of copies made, by department: 999,999
•
Max. no. of copies made, by copy mode: 999,999
•
Max. no. of copies made, by department/copy mode: 99,999
Distinguishable Copy
Modes
Up to 16 types
Power Source DC24V (supplied from copier)
Power Consumption 5W or less
Dimensions Width
Depth
Height
: 180 mm
: 564 mm
: 111 mm
Weight Approx. 550 g
Others A printer (option) recommended by Minolta can be hooked up,
sourced from another power supply.
Chapter 7
Specifications
203
