Konica Minolta EP2050 [172/225] When a warning message appears

•

Replace the Staple Cartridge only after the Add Staple Indicator lights up.

Removing the Staple Cartridge before then will result in stapling trouble.

•

Immediately after the new Staple Cartridge has been loaded, be sure to

follow steps 7 to 9.

NOTES

Manual

Staple

1139O2732A

Press the Manual Staple Key.

The Staple Sorter test-staples the

paper several times automatically.

1136O017AA

Remove the sheet of paper from

the 1st Bin and check that staples

have been driven into it.

If no staples are evident, place

another sheet of paper into the

1st Bin and repeat steps 7, 8, and

2. Detailed Instructions for Messages/Indicator Lights

Chapter 5

When a Warning Message Appears

160
