Konica Minolta EP2050 [197/225] Specifications
![Konica Minolta EP2050 [197/225] Specifications](/views2/1122110/page197/bgc5.png)
1. Copier Specifications
Warming-up Time 2 min. 30 sec. or less
at Ambient temperature of 20°C/68°F
(30 sec. or less when the Energy saving Mode is used)
First Copy Time A4C = 6.8 sec.
(in Full size Mode using First Copier Drawer)
Copying Speed
(approx. copies/min.)
First Copier Drawer
Full size (×1.000):
A3L: 14, A4L: 19, A4C: 25, B4L: 16
Reduction (×0.500):
A3L: 14, A4L: 19, A4C: 25, B4L: 16
Enlargement (×2.000):
A3L: 14, A4L: 19, A4C: 19, B4L: 16
Magnification Ratios Fixed ratios
Full size: 1 : 1 ±0.005
Reduction ratios: ×0.500, ×0.707, ×0.816,
Enlargement ratios: ×1.154, ×1.414, ×2.000
Zoom ratios: From ×0.500 to ×2.000
Zoom ratios: In ×0.001 increments
Multiple Copy Up to 99 copies (Count-Down system)
Exposure Control Auto and Manual
Power Requirements AC 110V, 115V, 120V, 127V, 200V/220V, 220V-240V 50/60 Hz
Power Consumption 1.5 kW (Max.)
Dimensions Width
Depth
Height
:
:
:
620 mm (Excluding Copy Tray)
685 mm
595 mm (up to Original Glass surface)
Weight 75 kg
(Excluding Copy Tray, Starter, Toner, Copy Paper)
Space Requirements Width
Depth
:
:
830 mm (Including Copy Tray)
685 mm
Chapter 7
Specifications
193
