Action
Change the setting of the User’s Choice (Auto Expo. Level).
➭
p. 135
Cancel the Auto Exposure Mode and select the Manual Exposure Mode, to adjust the
exposure level and obtain a darker image.
➭
p. 49
Press the Exposure Control Key (Darker) as necessary to obtain a darker image.
➭
p. 49
The copier needs more toner.
Press the Auxiliary Toner Replenishing Key as many times as required to obtain the
desired image density.
➭
p. 130
The copier needs more toner.
Press the Auxiliary Toner Replenishing Key as many times as required to obtain the
desired image density.
➭
p. 130
Replace the Toner Bottle with a new one.
➭
p. 146
Replace the paper.
➭
p. 148
Change the setting of the User’s Choice (Auto Expo. Level).
➭
p. 135
Cancel the Auto Exposure Mode and select the Manual Exposure Mode, to adjust the
exposure level and obtain a lighter image.
➭
p. 49
Press the Exposure Control Key (Lighter) as necessary to obtain a lighter image.
➭
p. 49
Wipe the Original Glass clean with a soft dry cloth.
➭
p. 208
Place the original in position so that it is held tightly against the Original Glass.
➭
p. 40
Replace the paper.
➭
p. 148
1. When this Type of Copy is Produced
Chapter 6
Troubleshooting
185
