4. User’s Choice
Finishing Priority
Determines the priority finishing mode when the copier is equipped with a
Sorter or Staple Sorter.
The initial setting is "Non Sort."
Auto Expo. Level
Determines the priority exposure level in the Auto Exposure Mode when the
copier has been set so that the Auto Exposure Mode is selected in the initial
mode.
The initial setting is "Normal."
Manual Expo. Adjust
Determines the priority exposure level in the Manual Exposure Mode when the
copier has been set so that the Manual Exposure Mode is selected in the initial
mode.
"Mode 1": For users who frequently use originals with halftone images, such
as photos
"Mode 2": For users who use a wide range of types of originals
"Mode 3": For users who frequently use originals with a colored background
or faint text
The initial setting is "Mode 1."
Sorter Priority:
Non Sort Sort
Group Staple
1136P409CA
1136P361CA
DarkerLighter
1234 56789
"Darker": Equivalent to EXP7
"Normal": Equivalent to EXP6
"Lighter": Equivalent to EXP5
1136P361CA
Auto Expo. Level:
Darker Normal
Lighter
1136P545CA
Manual Expo. Adj:
Mode 1 Mode 2
Mode 3
1136P411CA
Chapter 4
Special Functions
135
