DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

353

Figure 2-21 Managed AP Statistics – WLAN Summary window

The fields that can be displayed are described below:

Parameter Description

MAC Address

The Ethernet address of the Unified Switch-managed AP.

Packets Received

Total packets received by the AP on the wireless network.

Bytes Received

Total bytes received by the AP on the wireless network.

Packets Transmitted

Total packets transmitted by the AP on the wireless network.

Bytes Transmitted

Total bytes transmitted by the AP on the wireless network.

Click the MAC Address hyperlink to view detailed statistics about the AP.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

After clicking the Ethernet Summary tab under the Statistics tab, the following page will appear:

Figure 2-22 Managed AP Statistics – Ethernet Summary window
