DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

354

The fields that can be displayed are described below:

Parameter Description

MAC Address

The Ethernet address of the Unified Switch-managed AP.

Packets Received

Total packets received by the AP on the wired network.

Bytes Received

Total bytes received by the AP on the wired network.

Packets Transmitted

Total packets transmitted by the AP on the wired network.

Bytes Transmitted

Total bytes transmitted by the AP on the wired network.

Click the MAC Address hyperlink to view detailed statistics about the AP.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

After clicking the Detail tab under the Statistics tab, the following page will appear:

Figure 2-23 Managed AP Statistics – Detail window

Use the drop-down menu to view statistics for a specific AP that the Switch manages.

The fields that can be displayed are described below:

Parameter Description

WLAN Packets Received

Total packets received by the AP on the wireless network.

WLAN Bytes Received

Total bytes received by the AP on the wireless network.

WLAN Packets Transmitted

Total packets transmitted by the AP on the wireless network.

WLAN Bytes Transmitted

Total bytes transmitted by the AP on the wireless network.

WLAN Packets Received

Dropped

Number of packets received by the AP on the wireless network that were dropped.

WLAN Bytes Received

Dropped

Number of bytes received by the AP on the wireless network that were

dropped.

WLAN Packets Transmit

Dropped

Number of packets transmitted by the AP on the wireless network that were

dropped.

WLAN Bytes Transmit

Dropped

Number of bytes transmitted by the AP on the wireless network that were

dropped.
