DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

355

Ethernet Packets Received

Total packets received by the AP on the wired network.

Ethernet Bytes Received

Total bytes received by the AP on the wired network.

Ethernet Packets

Transmitted

Total packets transmitted by the AP on the wired network.

Ethernet Bytes Transmitted

Total bytes transmitted by the AP on the wired network.

Multicast Packets Received

Total multicast packets received by the AP on the wired network.

Total Receive Errors

Total receive errors detected by the AP on the wired network.

Total Transmit Errors

Total transmit errors detected by the AP on the wired network.

ARP Reqs Converted from

Bcast to Ucast

Number of ARP requests that the AP converted from a broadcast packet to a

unicast packet before sending to the wireless link.

Filtered ARP Reqs

Number of ARP requests that AP was able to drop instead of sending on the

wireless link.

Broadcasted ARP Requests

The number of ARP requests sent as broadcasts on the VAPs. This counter

does not include WDS links. The same ARP frame may be counted multiple

times when it is broadcasted on multiple VAPs. The counter is available even

when ARP suppression is disabled.

After clicking the Radio tab under the Statistics tab, the following page will appear:

Figure 2-24 Managed AP Statistics – Radio window

Use the drop down menu to select AP’s MAC address and click the radio button to select a radio to view the

detailed information about the packets and bytes transmitted and received on the radio (wireless) interface of a

particular access point managed by the Switch.

The fields that can be displayed are described below:

Parameter Description

WLAN Packets Received

Total packets received by the AP on this radio interface.

WLAN Bytes Received

Total bytes received by the AP on this radio interface.

WLAN Packets Transmitted

Total packets transmitted by the AP on this radio interface.

WLAN Bytes Transmitted

Total bytes transmitted by the AP on this radio interface.
