DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide

364

Figure 2-34 Associated Clients Status - Summary window

The fields that can be displayed are described below:

Parameter Description

MAC Address

The Ethernet address of the client station. If the MAC address is followed by an

asterisk (*), the client is associated with an AP managed by a peer switch.

Detected IP Address

Display the IPv4 address of the client.

NetBIOS Name

The NetBIOS name of the wireless client. For Microsoft Windows hosts, the NetBIOS

name is typically the same as, or based on the host name of the client.

SSID

The network on which the client is connected.

BSSID

The Ethernet MAC address for the managed AP VAP where this client is associated.

Channel

The operating channel for the client association.

Status

Display whether or not the client has associated and/or authenticated. The valid

values are:

• Associated - The client is current associated to the managed AP.

• Authenticated - The client is currently associated and authenticated to the

managed AP.

• Disassociated - The client has disassociated from the managed AP, if the client

does not roam to another managed AP within the client roam timeout, it will be

deleted.

Network Time

Display the amount of time that has passed since this client first authenticated with

the network.

Tick the specific check box and click the Disassociate button to disassociate the client from the managed AP.

Click the Disassociate All button to disassociate all clients from the managed AP.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

After clicking the Detail tab under the Status tab, the following page will appear:
