DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide
369
Figure 2-39 Associated Clients SSID Status window
The fields that can be displayed are described below:
Parameter Description
SSID
The network on which the client is connected.
Client MAC Address
The Ethernet address of the client station.
Tick the specific check box and click the Disassociate button to disassociate the client from the managed AP.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
After clicking the VAP Status tab, the following page will appear:
Figure 2-40 Associated Clients VAP Status window
The fields that can be displayed are described below:
Parameter Description
