DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide
380
Figure 2-51 Detected Client Summary –Roam History window
The fields that can be displayed are described below:
Parameter Description
MAC Address
MAC address of the detected client.
AP MAC Address
MAC Address of the managed AP to which the client authenticated.
Radio Interface Number
Radio Number to which the client is authenticated.
VAP MAC Address
VAP MAC address to which the client roamed.
SSID
SSID Name used by the VAP.
New Authentication
A flag indicating whether the history entry represents a new authentication or a
roam event.
Age
Time since the history entry was added.
After clicking the Pre-Authentication History Summary tab, the following page will appear:
