DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide
381
Figure 2-52 Detected Client Pre-Authentication History Summary window
The fields that can be displayed are described below:
Parameter Description
MAC Address
MAC address of the detected client.
AP MAC Address
MAC Address of the managed AP to which the client has pre-authenticated.
This field can show a history of up to ten pre-authentications for each client.
After clicking the Roam History Summary tab, the following page will appear:
Figure 2-53 Detected Client Roam History Summary window
The fields that can be displayed are described below:
Parameter Description
MAC Address
MAC address of the detected client.
