SiBE311209 Protection Control
Function 102
7.3 Discharge Pipe Protection Control
This discharge pipe protection control is used to protect the compressor internal temperature
against an error or transient increase of discharge pipe temperature.
This control is performed by each compressor.
[INV. compressor]
∗ The following control is performed for each compressor of outdoor (and function unit).
[STD compressor]
∗ For systems with multi outdoor units, the control shown below is conducted by outdoor
unit.
Normal operation
HTdi > 115°C HTdi < 100°C
I
NV. compressor (see ∗1):
1 step down
&
• HTdi < 110°C
• A lapse of 20 sec.
&
• HTdi > 115°C
• A lapse of 30 sec.
INV. compressor (see ∗1):
1 step up
Master + Slave units
HTdi > 120°C continues
for a period of 90 sec.
Compressor:
62 Hz + ON + OFF
HTdi > 120°C continues
for a period of 90 sec.
Compressor (see ∗2):
62 Hz + OFF + OFF
Master unit
HTdi: Value obtained by
correcting the discharge
pipe temperature (Tdi) of
INV. compressor with
outdoor air temperature.
∗1: For INV. compressor
steps, refer to information
on P.92 and 93.
Lower limit of compressor
step on this control:
62 Hz + OFF + OFF
OR
• HTdi > 135°C
• HTdi > 120°C continues for a period of 10 min.
Discharge pipe temperature standby
occurs 3 times in a period of 100 min.
Restart standby: 10 min.
(2 times per 100 min. at maximum)
Stop due to error
(
“
F3
”
displayed)
OR
Normal operation
10 min.
• HTds > 120°C continues for a period of
continuous 5 min. or more
• HTds > 135°C
STD compressor stops
HTdS: Value of STD compressor discharge
pipe temperature (Tds) compensated
with outdoor air temperature.
