SiBE311209 Test Operation
Test Operation 138
11.Complete
The display on the remote controller shows a blinking
"
PE
" code for signalling that automatic
charging will be finished in about 10 minutes.
When the unit stops operating, close valve A immediately and check the LEDs and check if
the "
P9" code is displayed on the remote controller.
If the LED indication is not as shown above, correct the error (as indicated in the display of
the remote controller) and restart the complete charging procedure. When the charging
amount is little, the "
PE
" code may not be displayed, but instead the "
P9
" code will be
displayed immediately.
Beware of the fan blades when you open the front panel.
The fan may still rotate for a while after unit operation has stopped.
When the unit displays an out of temperature range, the automatic charging of refrigerant
can not be completed.
Out of outdoor air temperature range
Complete the charging of refrigerant on another time when the outdoor air temperature is
warmer than 0°C DB and colder than 43°C DB.
Out of indoor temperature range
Complete the charging of refrigerant on another time when the indoor temperature is
warmer than 20°C DB and colder than 32°C DB.
12.In case leak detection function required
Press the BS4 TEST button once for post-processing with regard to the leak detection
function and press the BS1 MODE button to confirm that charging is completed.
Record the amount that was added on the additional refrigerant charge label provided with
the unit and attach it on the back side of the front panel.
Perform the procedure "1.3.4 Procedure for Inputting the Additional Refrigerant Charge
Weight into the PCB" as described on P.140.
12.In case leak detection function not required
Press the BS1 MODE button once and the charging is complete.
Record the amount that was added on the additional refrigerant charge label provided with
the unit and attach it on the back side of the front panel.
Perform the procedure "1.3.4 Procedure for Inputting the Additional Refrigerant Charge
Weight into the PCB" as described on P.140.
H1P H2P H3P H4P H5P H6P H7P
lllkkkk
H1P H2P H3P H4P H5P H6P H7P
kllkkkk
H1P H2P H3P H4P H5P H6P H7P
klllkhh
H1P H2P H3P H4P H5P H6P H7P
klllhkh
