SiBE311209 Troubleshooting by Remote Controller
Service Diagnosis 202
3.8 List of Error Code
k: ON h: OFF l: Blink
Error code Operation
lamp
Inspection
display
Unit No. Error contents Page
Referred
Indoor Unit A0 lllError of external protection device 208
A1 lllIndoor unit PCB defect 209
A3 lllDrain level control system abnormality 210
A6 lllFan motor (M1F) lock, overload 212
214
215
A7 khlSwing flap motor abnormality 218
A9 lllElectronic expansion valve abnormality / Dust
clogging
220
222
AF khlDrain level about limit 223
AH khlAir filter maintenance abnormality —
AJ lllCapacity determination device abnormality 224
C4 lllHeat exchanger thermistor abnormality (loose
connection, disconnection, short circuit, failure)
225
C5 lllGas pipes thermistor abnormality (loose
connection, disconnection, short circuit, failure)
226
C9 lllSuction air thermistor abnormality (loose
connection, disconnection, short circuit, failure)
227
CA lllDischarge air thermistor abnormality (loose
connection, disconnection, short circuit, failure)
228
CJ kkkRoom temperature thermistor in remote controller
abnormality
229
Outdoor Unit
Function
Unit
E1 lllPCB defect 230
E3 lllHigh pressure switch abnormality 231
E4 lllLow pressure sensor abnormality 233
E5 lllInverter compressor motor lock 235
E6 lllSTD compressor meter overcurrent / lock 237
E7 lllOutdoor unit fan motor abnormality 238
E9 lllElectronic expansion valve coil abnormality 241
F3 lllDischarge pipe temperature abnormality 243
F6 lllRefrigerant overcharged 245
H7 lllAbnormal outdoor unit fan motor signal 246
H9 lllOutdoor air thermistor abnormality (loose
connection, disconnection, short circuit, failure)
248
J2 lllCurrent sensor abnormality 249
J3 lllDischarge pipe thermistor abnormality (loose
connection, disconnection, short circuit, failure)
250
J4 lllHeat exchanger gas pipe temperature thermistor
abnormality
251
J5 lllSuction pipe thermistor abnormality (loose
connection, disconnection, short circuit, failure)
252
J6 lllOutdoor unit heat exchanger thermistor abnormality
(loose connection, disconnection, short circuit,
failure)
253
J7 lllLiquid pipe thermistor abnormality 254
J8 lllLiquid pipe thermistor 2 abnormality 255
J9 lllSubcooling heat exchanger gas pipe thermistor
abnormality
256
JA lllHigh pressure sensor abnormality 257
JC lllLow pressure sensor abnormality 259
L1 lllDefective inverter PCB 261
L4 lllInverter radiation fin temperature rise error 263
L5 lllMomentary overcurrent of inverter compressor 264
L8 lllOvercurrent of inverter current 265
L9 lllInverter compressor starting error 267
The system operates for error codes indicated in black squares, however, be sure to check and repair.
