Troubleshooting by Indication on the Remote Controller SiBE311209
225 Service Diagnosis
4.9 Heat Exchanger Thermistor (R2T) Abnormality
Remote
Controller
Display
C4
Applicable
Models
All indoor unit models
Method of Error
Detection
Error detection is carried out by temperature detected by heat exchanger thermistor.
Error Decision
Conditions
When the heat exchanger thermistor becomes disconnected or shorted while the unit is running
Supposed
Causes
Defective thermistor (R2T) for liquid pipe
Defective indoor unit PCB
Troubleshooting
Refer to P.314.
Caution
Be sure to turn off the power switch before connecting or disconnecting
connectors, or parts may be damaged.
NO
Normal (The error is caused by
defective contact.)
YES
YES
NO
Remove the thermistor from
the indoor unit PCB, and then
insert it again.
Replace the thermistor (R2T).
Replace the indoor unit PCB.
Remove the thermistor from the
indoor unit PCB, and then make
resistance measurement of the
thermistor using a multiple
meter.
Is the thermistor
normal?
5 kΩ to 90 kΩ
CHECK 11
CHECK 11
