SiBE311209 Troubleshooting by Indication on the Remote Controller
Service Diagnosis 268
Troubleshooting
Refer to P.307.
Continued from the previous page.
(Starting error due to aged operation.)
CHECK 4
Check if the
power transistor
is normal.
NO
Cancel the melting state of
refrigerant.
Refrigerant is
melting. (The unit is
out of power supply
for more than 6
hours.)
Is the insulation
resistance of the
compressor 100k
Ω
or more?
Is the inside of
compressor
broken?
YES
NO
YES
NO
YES
Replace the inverter compressor.
Replace the inverter compressor.
Replace the compressor inverter
PCB.
Recheck the compressor/
refrigerant circuit.
NO
YES
CHECK 4
