Troubleshooting by Indication on the Remote Controller SiBE311209
285 Service Diagnosis
4.50 Transmission Error (Across Outdoor Units and Function
Units)
Remote
Controller
Display
U7
Applicable
Models
Outdoor Unit: RTSQ8~16PAY1
Function Unit: BTSQ20PY1
Method of Error
Detection
Micro-computer checks if transmission across outdoor units and between outdoor units and
function units.
Error Decision
Conditions
When transmission is not carried out normally for a certain amount of time
Supposed
Causes
Connection error in transmission wires between outdoor unit and external control adaptor for
outdoor unit
Connection error in transmission wires across outdoor units and between outdoor units and
function units
Setting error in switching cooling/ heating
Unified address setting error for cooling/ heating
(function unit, external control adaptor for outdoor unit)
Defective outdoor unit PCB (A1P or A3P)
Defective external control adaptor for outdoor unit
