Troubleshooting by Indication on the Remote Controller SiBE311209
271 Service Diagnosis
4.41 Inverter Over-Ripple Protection
Remote
Controller
Display
P1
Applicable
Models
Outdoor Unit: RTSQ8~16PAY1
Function Unit: BTSQ20PY1
Method of Error
Detection
Imbalance in supply voltage is detected in PCB.
Error Decision
Conditions
When imbalance in supply voltage is in excess of 14V.
∗ Error is not decided while the unit operation is continued.
"
P1
" will be displayed by pressing the inspection button.
Supposed
Causes
Open phase
Voltage imbalance between phases
Defective main circuit capacitor
Defective inverter PCB
Defect of K2M relay in inverter PCB
Improper main circuit wiring
