Troubleshooting by Indication on the Remote Controller SiBE311209
269 Service Diagnosis
4.40 Transmission Error between Inverter and Control PCB
Remote
Controller
Display
LC
Applicable
Models
Outdoor Unit: RTSQ8~16PAY1
Function Unit: BTSQ20PY1
Method of Error
Detection
Check the communication state between inverter PCB and control PCB by micro-computer.
Error Decision
Conditions
When the correct communication is not conducted in certain period
Supposed
Causes
Defective connection between the inverter PCB and outdoor unit main PCB
Defective outdoor unit main PCB (transmission section)
Defective inverter PCB
Defective noise filter
Defective fan inverter
Incorrect type of inverter PCB
Defective inverter compressor
Defective fan motor
External factor (noise etc.)
Troubleshooting
∗1. List of Inverter PCB
Applicable Models
PC0509-1
RTSQ8 ~ 16PA
BTSQ20P
Caution
Be sure to turn off the power switch before connecting or disconnecting
connectors, or parts may be damaged.
Was the PCB (A1P)
replaced with a
spare PCB?
YES
Make correct model setting.
(For setting procedure, refer to
information on P.169.)
Does the model setting
of the spare PCB match
the system?
Are the connectors
of the inverter PCB,
outdoor unit main
PCB, and sub PCB
all securely
connected?
Is the type of the
inverter PCB
correct?(∗1)
YES
NO
NO
NO
YES
NO
YES
A
Properly connect the connectors.
Replace it with a correct
PCB.
