SiBE311209 Troubleshooting by Indication on the Remote Controller
Service Diagnosis 308
Check for Causes of Wet Operation.
Referring to the Fault Tree Analysis (FTA) shown below, probe the defective points.
Note: ∗1. “Superheating temperature control” in cooling is conducted by indoor unit electronic
expansion valve.
∗2. Superheating temperature control in heating is conducted by outdoor unit electronic
expansion valve (EVM).
∗3. Guideline of superheated degree to judge as wet operation
1 Suction gas superheated degree: Not more than 3°C; 2 Discharge gas superheated
degree: Not more than 15°C, except immediately after compressor starts up or is running
under drooping control.
(Use the above values as a guide. Depending on the other conditions, the unit may be
normal despite the values within the above range.)
CHECK 5
Refrigerant accumulation
Overcharge of refrigerant
Defective crankcase heater
Frequent ON/OFF of compressor
[In cooling]
Indoor unit
electronic
expansion
valve opens too
much. (∗1)
[In heating]
Outdoor unit
electronic
expansion
valve opens too
much. (∗2) (∗3)
Defective control
of superheated
degree
Defective
indoor unit
electronic
expansion
valve
Defective
outdoor unit
electronic
expansion
valve
Defective
control
Defective
control
Defective valve coil
Defective service monitor PCB
Defective valve body
Defective valve coil
Defective valve body
Defective low pressure sensor
Defective suction pipe thermistor
Defective service monitor PCB
←Are the coil resistance and
insulation normal?
←Is the connector properly connected?
Are the thermistor resistance
characteristics normal?
←Is the connector properly connected?
Are the thermistor resistance
characteristics normal?
←
Are the coil resistance and
insulation normal?
←Are the electric characteristics normal?
←Is the connector properly connected?
Are the thermistor resistance
characteristics normal?
←Is the pressure value checked with the
Service Checker corresponding to the
measurement value of the pressure
sensor?
←Can the fan motor be rotated
with hands?
Are the motor coil resistance and
insulation normal?
←Is the air filter clogged?
←Is there any obstacle in the
airflow passage?
Wet operation
Degraded
evaporating
capacity
High
airflow
passage
resistance
Dirty evaporator
Decreased
airflow rate
Decreased
fan output
Defective fan motor
Dirty filter
Obstacles
←Does the heat exchanger get clogged?
Defective service
monitor PCB (including
capacity setting)
Defective gas pipe
thermistor of indoor unit
Defective liquid pipe
thermistor of indoor unit
←
Refer to Check 6
