Function General SiBE311209
83 Function
1.2 Symbol
Symbol Electric symbol Description or function
20SA Y3S Four way valve (Heat exchanger switch)
20SB Y2S Four way valve (High/low pressure gas pipe switch)
DSH –
Discharge pipe superheated degree (Discharge pipe temp.–high pressure equivalent saturation
temp.)
DSHi – Discharge pipe superheated degree of INV. compressor
DSHs – Discharge pipe superheated degree of STD compressor
EV – Opening degree of electronic expansion valve
EVM Y1E Electronic expansion valve for main heat exchanger
EVT Y3E Electronic expansion valve for subcooling heat exchanger
EVJ Y2E Electronic expansion valve at the refrigerant charge port
HTdi –
Value of INV. compressor discharge pipe temperature compensated with outdoor air
temperature
HTds –
Value of STD compressor discharge pipe temperature compensated with outdoor air
temperature
Pc S1NPH Value detected by high pressure sensor
Pe S2NPL Value detected by low pressure sensor
HPS S1PH~S3PH
This function when the pressure increases to stop operation and avoid high pressure increase
in the fault operation.
SH –
Evaporator outlet superheated degree (Suction pipe temp.–low pressure equivalent saturation
temp.)
SHS – Target evaporator outlet superheated degree
SVE Y6S Main bypass solenoid valve
SVP Y5S Solenoid valve for hot gas
SVL Y4S Refrigerant regulator liquid pipe solenoid valve
SVG Y1S Refrigerant regulator gas vent pipe solenoid valve
SVO Y7S Refrigerant regulator discharge pipe solenoid valve
SVT Y8S Refrigerant regulator discharge pipe solenoid valve
SVHG Y9S
Solenoid valve
Bypass the high pressure gas to the outdoor unit heat exchanger. (Heat exchanger hot gas)
Ta R1T Outdoor air temperature
TsA R8T Suction pipe temperature
Tb R4T Heat exchanger outlet temperature at cooling
Tc – High pressure equivalent saturation temperature
TcS – Target temperature of Tc
Tdi R31T Discharge pipe temperature of INV. compressor
Tds R32T, R33T Discharge pipe temperature of STD compressor
Te – Low pressure equivalent saturation temperature
TeS – Target temperature of Te
Tf R7T Temperature of liquid pipe between heat exchanger and main electronic expansion valve
Tfin R1T Radiation fin temperature
Tg R2T Heat exchanger gas pipe temperature
Tl R6T Liquid pipe temperature detected with the liquid pipe thermistor
Tsc R9T Temperature of liquid pipe between liquid stop valve and subcooling heat exchanger
Tsh R5T Temperature of gas pipe at the subcooling heat exchanger evaporation side
