SiBE311209 Test Operation
Test Operation 140
Remote controller heating mode error codes
Remote controller cooling mode error codes
1.3.4
Procedure for Inputting the Additional Refrigerant Charge Weight into
the PCB
Availability of the leak detection function feature requires input of the additional refrigerant
charge amount immediately after finishing the automatic charging. The input must be executed
before performing the test operation.
If a wrong value is input for the additional charged refrigerant weight, the accuracy of the leak
detection function will decrease.
Procedure
1. Close the el. compo. box lid and all front panels except the one on the side of the el compo.
box.
2. Press and hold the BS1 MODE button for 5 seconds to enter into setting mode 2.
The H1P LED is ON
k
.
3. Press the BS2 SET button 14 times.
The LED display must be as follows:
Press the BS3 RETURN button once as confirmation of the LEDs combination.
LEDs will be blinking in function of the last entered setting (factory setting = 0 kg).
4. The weighed and already recorded amount of additional refrigerant charge (not the total
amount of refrigerant present in the system) must be entered by selecting the corresponding
LED display.
Scroll through the possible LED combinations by pressing the BS2 SET button until the LED
combination corresponds to the weight of additional refrigerant charge you must input.
Select the required input by pressing the BS3 RETURN button and confirm the input into the
PCB by pressing the BS3 RETURN button again.
3. Remote controller error code display
Error code
P8
recharge
operation
Close valve A immediately and press the TEST OPERATION button once.
The operation will restart from the charging mode judgement onwards.
P2
charge hold
Close valve A immediately. Check following items:
- Check if the gas stop valve is opened correctly
- Check if the valve of the refrigerant cylinder is
opened
- Check if the air inlet and outlet of the indoor unit are
not obstructed
After correcting the
abnormality, restart the
automatic charging
procedure again.
Error code
PE
Charging is almost finished. Ready to close valve A.
P9
Charging is finished. Close valve A and remove the refrigerant tank.
PA
,
PH
replace the
cylinder
Close valve A and replace the empty cylinder.
After replacing the cylinder, open valve A again and continue the work (the outdoor
unit will not stop operating).
P8
recharge
operation
Close valve A immediately.
Restart the automatic charging procedure again.
P2
charge hold
Close valve A immediately. Check following items:
- Check if the high pressure/low pressure gas pipe,
suction gas pipe and liquid pipe stop valves are
opened correctly
- Check if the valve of the refrigerant cylinder is opened
- Check if the air inlet and outlet of the indoor unit are
not obstructed
After correcting the
abnormality, restart the
automatic charging
procedure again.
∗
abnormal
stop
Close valve A immediately. Confirm the error code by
the remote controller and correct the abnormality by
following the "Correcting after abnormal completion of
the check operation" on P.144.
H1P H2P H3P H4P H5P H6P H7P
khhkkkh
