SiBE311209 Troubleshooting by Indication on the Remote Controller
Service Diagnosis 302
4.57 System Abnormality, Refrigerant System Address
Undefined
Remote
Controller
Display
UH
Applicable
Models
All indoor unit models
Outdoor Unit: RTSQ8~16PAY1
Method of Error
Detection
Detect an indoor unit with no address setting.
Error Decision
Conditions
The error decision is made as soon as the abnormality aforementioned is detected.
Supposed
Causes
Improper connection of transmission wiring between indoor-outdoor units and outdoor-
outdoor units
Defective indoor unit PCB
Defective outdoor unit main PCB (A1P or A3P)
