Field Setting SiBE311209
155 Test Operation
In the Case of FXFQ100~125 (All round outlet)
In the Case of FXFQ25~80 (
∗2
4-Way, 3-Way, 2-Way Outlets)
In the Case of FXFQ100~125 (
∗2
4-Way, 3-Way, 2-Way Outlets)
In the Case of FXUQ71~125
Note: ∗1 “Mode No.” setting is done in a batch for the group. To make or confirm settings for an
individual unit, set the internal mode number in parentheses.
∗2 The figure of the ceiling height is for the all round outlet. For the settings for 4-direction (part
of corner closed off), 3-direction and 2-direction outlets, see the installation manual supplied
with the separately sold sealing material kit.
(14) Airflow Direction Setting
Set the airflow direction of indoor units as given in the table below. (Set when sealing material
kit of air discharge outlet has been installed.) The second code No. is factory setting to “01.”
Setting Table
Mode
No.
First
code
No.
Second
code
No.
Setting Ceiling height (m)
13 (23) 0
01
Standard · All
round outlet
≤ 3.2
02 High Ceiling (1) 3.2 - 3.6
03 Higher Ceiling (2) 3.6 - 4.2
Mode
No.
First
code
No.
Second
code
No.
Setting
Ceiling height
4-way Outlets 3-way Outlets 2-way Outlets
13 (23) 0
01 Standard (N) Lower than 3.1 m Lower than 3.0 m Lower than 3.5 m
02 High Ceiling (H) Lower than 3.4 m Lower than 3.3 m Lower than 3.8 m
03 Higher Ceiling (S) Lower than 4.0 m Lower than 3.5 m —
Mode
No.
First
code
No.
Second
code
No.
Setting
Ceiling height
4-way Outlets 3-way Outlets 2-way Outlets
13 (23) 0
01 Standard (N) Lower than 3.4 m Lower than 3.6 m Lower than 4.2 m
02 High Ceiling (H) Lower than 3.9 m Lower than 4.0 m Lower than 4.2 m
03 Higher Ceiling (S) Lower than 4.5 m Lower than 4.2 m —
Mode
No.
First
code
No.
Second
code
No.
Setting
Ceiling height
4-way Outlets 3-way Outlets 2-way Outlets
13 (23) 0
01 Standard (N) Lower than 2.7 m Lower than 3.0 m Lower than 3.5 m
02 High Ceiling (H) Lower than 3.0 m Lower than 3.5 m Lower than 3.8 m
03 Higher Ceiling (S) Lower than 3.5 m Lower than 3.8 m —
Mode No. First Code No.
Second Code
No.
Setting
13 (23) 1
01 F: 4-direction airflow
02 T: 3-direction airflow
03 W: 2-direction airflow
