SiBE311209 Field Setting
Test Operation 184
3.2.10 Emergency Operation
If any of the compressors causes a failure, the relevant compressor or the relevant outdoor unit
will be prohibited from running, and emergency operation will be conducted only with an
operable compressor or outdoor unit.
The emergency operation can be conducted by resetting the remote controller or making
outdoor unit PCB setting.
(1) Emergency operation by resetting the remote controller (Automatic backup operation)
If a certain outdoor unit circuit causes a failure (i.e., the system stops operation or the indoor
unit remote controller displays error), the defective outdoor unit or function unit will be prohibited
from running for a period of eight hours through the indoor unit remote controller setting for a
period of eight hours, and emergency operation will be conducted only with an operable outdoor
unit.
[Emergency operation procedure]
· If the outdoor unit or the function unit stops running due to an error, reset the remote controller
(i.e., press and hold the ON/OFF button of the remote controller for a period of not less than 4
seconds).
[Detail]
(2) Emergency operation by making outdoor unit PCB setting (Manual backup operation)
If any of the compressors stops running due to error, emergency operation will be conducted
only with an operable compressor or outdoor unit by setting the relevant compressor,
outdoor unit or function unit into "operation prohibited" according to the outdoor unit PCB
setting.
· The outdoor unit or the function unit in which error occurs will
be prohibited from running, and other outdoor units will run.
E3, E4, E5, E7 (∗1), F3
H7 (∗1), H9
J2, J3, J5, J6, J7, J9, JA, JC
L3, L4, L5, L8, L9, LC, U2, UJ
· Error codes that enable the emergency operation are as listed above.
∗1:
While in heating operation, if
"
E7
"
or
"
H7
"
error occurs, the emergency operation will be disabled.
Applicable model
RTSYP10PA RTSYP14 · 16PA RTSYP20PA Remark
Detail of setting
By compressor
Setting of INV.
compressor to
operation prohibited
with outdoor unit
(master unit)
Set the setting item
No. 42 to "INV.
compressor operation
prohibited".
(Applicable to
c
)
Set the setting item
No. 42 to "INV.
compressor operation
prohibited".
(Applicable to
f
)
— Set with outdoor unit.
Setting of STD
compressor 1 and 2 to
operation prohibited
with outdoor unit
(master unit)
Set the setting item
No. 19 to "STD
compressor 1, 2
operation prohibited".
(Applicable to
d
)
Set the setting item No.
19 to "STD compressor
1, 2 operation
prohibited". (Applicable
to
g
and
h
)
— Set with outdoor unit.
Setting of STD
compressor 2 to
operation prohibited with
outdoor unit (master unit)
—
Set the setting item No.
19 to "STD compressor
2 operation prohibited".
(Applicable to
h
)
— Set with outdoor unit.
By unit
Setting of master unit to
operation prohibited
with outdoor unit
(master unit)
——
Set the setting item
No. 38 to "Master unit
operation prohibited".
(Applicable to
j
)
Set with master unit.
(CAUTION) Setting
with slave unit will be
invalidated.
Setting of slave unit to
operation prohibited
with outdoor unit
(master unit)
——
Set the setting item
No. 39 to "Slave unit
operation prohibited".
(Applicable to
k
)
Set with master unit.
(CAUTION) Setting
with slave unit will be
invalidated.
Setting to operation
prohibited with function
unit
Set the setting item No.
42 to "INV. compressor
operation prohibited".
(Applicable to
e
)
Set the setting item No.
42 to "INV. compressor
operation prohibited".
(Applicable to
i
)
Set the setting item No.
42 to "INV. compressor
operation prohibited".
(Applicable to
l
)
Set with function unit.
(CAUTION) Setting with
outdoor unit will prohibit the
operation of the outdoor unit
INV. compressor.
Remark
INV.
STD1
INV.
(1) (2) (3)
INV.
STD1
INV.
(4) (5) (7)
STD2
(6)
INV.
STD1
INV.
(8) (9) (10)
INV.
