Troubleshooting by Indication on the Remote Controller SiBE311209
257 Service Diagnosis
4.33 High Pressure Sensor Abnormality
Remote
Controller
Display
JA
Applicable
Models
Outdoor Unit: RTSQ8~16PAY1
Function Unit: BTSQ20PY1
Method of Error
Detection
Error is detected from the pressure detected by the high pressure sensor.
Error Decision
Conditions
When the high pressure sensor is short circuit or open circuit
(Not less than 4.22MPa, or 0.01MPa and below)
Supposed
Causes
Defective high pressure sensor system
Connection of low pressure sensor with wrong connection
Defective outdoor unit PCB (A1P)
Defective connection of high pressure sensor
