SiBE311209 Troubleshooting by Indication on the Remote Controller
Service Diagnosis 274
4.43 Field Setting Abnormality after Replacing Main PCB or
Combination of PCB Abnormality
Remote
Controller
Display
PJ
Applicable
Models
Outdoor Unit: RTSQ8~16PAY1
Function Unit: BTSQ20PY1
Method of Error
Detection
This error is detected according to communications with the inverter.
Error Decision
Conditions
Make judgement according to communication data on whether or not the type of the inverter
PCB is correct.
Supposed
Causes
Defective (or no) field setting after replacing outdoor unit main PCB
Mismatching of type of PCB
