SiBE311209 Protection Control
Function 104
7.5 STD Compressor Overload Protection
∗ This control is used to prevent abnormal heating due to overcurrent to the compressor
resulting from failures of STD compressor such as locking.
7.6 Cooling Fan Control for Radiation Fin Temperature of
Function Unit
When the radiation fin temperature of function unit rises, it is cooled with the fan (M1F) as
follows.
7.7 Heater Control for Function Unit Switch Box
The heater (E2HC) places to the function unit switch box to prevent freezing by low outdoor air
temperature, and it is controlled as follows by the outdoor air temperature.
The operation range of function unit “ON” (Outdoor air temp. < -20°C)
“OFF” (Outdoor air temp. > -17°C)
The range of compressor stop “ON” (Outdoor air temp. < -17°C)
“OFF” (Outdoor air temp. > -14°C)
STD compressor ON
Demand to operate. CT detection current value >14.95A
STD compressor OFF for 30 min.
When occurring 3 times within 90 min.,
the error code “
E6
” is output.
Fan OFF
&
OR
52C1 = ON
Radiation Fin Temp. thermistor > 50°C
52C1 = OFF
Radiation Fin Temp. thermistor < 30°C
Fan ON
