Daikin FXSQ32P7VEB [242/370] Low pressure sensor abnormality
![Daikin FXSQ80PVE4 [242/370] Low pressure sensor abnormality](/views2/1696757/page242/bgf2.png)
Troubleshooting by Indication on the Remote Controller SiBE311209
233 Service Diagnosis
4.16 Low Pressure Sensor Abnormality
Remote
Controller
Display
E4
Applicable
Models
Outdoor Unit: RTSQ8~16PAY1
Method of Error
Detection
Abnormality is detected by the pressure value with the low pressure sensor.
Error Decision
Conditions
Error is generated when the low pressure is dropped under compressor operation.
Operating pressure: 0.07MPa
Supposed
Causes
Abnormal drop of low pressure (Lower than 0.07MPa)
Defective low pressure sensor
Defective outdoor unit PCB
Stop valve is not opened
